The BlazeCut Alarm Panel AAP400 is a simple and effective optional device for monitoring system status and component functionality. It can be used with the full range of BlazeCut fire suppression systems, where only automatic system activation is required.

Durable powder coated aluminium body
Fault and disconnection identification
Compatible with C Series and T Series
Can be used as an independent fire warning device (not requiring extinguishing system)
Small footprint design
Universal flush or surface mounting
Test /reset button
Audible and visual fire signalling
IP65 rated and EMC tested (EHK 10-06)

Parameter	Description
Material of body	Red powder coated aluminium
Dimensions (LxWxH)	64x58x30 mm (excluding cable gland)
Operation temperature	from -30 °C to +70 °C
Ingress protection	IP65 rated (boxed version)
Operation voltage	from 10 V DC to 30 V DC
External cable	0.5 m cable, core 6x Ø 0.5 mm
Sound power	85 dB @ 10 cm distance
External fuse	200 mA
Maximum current draw at 12 V DC	140 mA (at 12 V DC), 70 mA (at 24 V DC)
Luminous intensity of LED lights	300 mcd
Monitoring frequency	10 Hz
